PE Jaw Crusher Series
Model：
PE-1500×1800
Size of Feeding Port：
1500x1800mm
Maximum Feed Particle Size：
1200mm
Throughput：
1300-1800t/h
COLLECT
South China Machine Industry Co., Ltd.
Guangdong · GuangzhouMain Products：Mining equipment and accessories
Enter the store
︿
﹀
Details Parameters
Details Introduction
PE JAW CRUSHER SERIES
PE Series Jaw Crusher (abbreviated as jaw crusher) is primarily used for coarse and fine crushing of various ores and bulk materials with compressive strength not exceeding 350 MPa. It is widely applied in industries such as mining, metallurgy, building materials, highways, railways, water conservancy, and chemical engineering.
PRODUCT FEATURES
1. High crushing ratio with large throughput.
2. Simple structure, easy maintenance.
3. Safe and reliable, effortless servicing.
4. Energy-efficient design with a long service life .
TECHNICAL SPECIFICATIONS
| Model | Feed opening size (mm) | Maximum feed size (mm) |
Disalusting port range (mm×mm) | Capacity (t/h) | Motor power(kw) | Weight (excluding motor) = (T) |
| PE-500×750 | 500×750 | 425 | 50-150 | 50-100 | 55 | 11.2 |
| PE-600×900 | 600×900 | 500 | 60-175 | 80-180 | 75 | 16.7 |
| PE-750×1060 | 750×1060 | 630 | 100-250 | 200-350 | 110 | 27 |
| PE-870×1060 | 870×1060 | 700 | 100-250 | 300-500 | 132 | 32 |
| PE-900×1200 | 900×1200 | 750 | 100-250 | 400-700 | 160 | 45 |
| PE-1000×1200 | 1000×1200 | 800 | 100-250 | 500-900 | 185 | 48 |
| PE-1200×1500 | 1200×1500 | 1000 | 150-300 | 800-1200 | 250 | 88 |
| PE-1300×1600 | 1300×1600 | 1100 | 150-300 | 1000-1600 | 400 | 102 |
| PE-1500×1800 | 1500×1800 | 1200 | 200-350 | 1300-1800 | 500-630 | 132 |
