Agitation Vat
Model：
XB3500
EffectiveVolume：
30m³
Rotation Speed of Impeller：
230r/min
Weight：
7300kg
COLLECT
Chenzhou Hengda Mineral Processing Machinery Co., Ltd.
Hunan · ChenzhouMain Products：Mineral processing equipment
Enter the store
︿
﹀
Details Parameters
Details Introduction
This machine can be applied to a variety of metal ores and is mainly used for pulp mixing before flotation operations. It is typically used in pulp mixing when its thickness is not more than 30% (by weight), and the solid component in the pulp (less than 1 mm) is fully mixed with the flotation agent. It can also be used for mixing other non-metallic minerals.
The machine can be divided into two different types—the push-through type and the lift type—according to its structure. The lift type is used for lifting the pulp to compensate for the lack of pulp circulation at different elevations in the mineral sorting process. It can raise the pulp up to 1.2 meters high.
MAIN MODELS AND TECHNICAL PARAMETERS:
| Model and specification | Dimensions (Diameter×Height) (mm) | Effective volume (m³) | Impeller diameter(mm) | Impeller rotation speed(r/min) | Motor (kw) |
Weight(kg) | Overall dimensions (L×W×H) (mm) | |
| Agitation vat | XB1000 | Φ1000×1000 | 0.58 | 480 | 330 | Y132S-6 3kw |
790 | 1150×1110×1540 |
| XB1200 | Φ1200×1200 | 1.4 | 480 | 330 | Y132S-6 3kw |
940 | 1650×1330×1650 | |
| XB1500 | Φ1500×1500 | 2.2 | 520 | 280 | Y132M2-6 5.5kw |
1200 | 1700×1660×2300 | |
| XB2000 | Φ2000×2000 | 5.5 | 550 | 240 | Y160M-6 7.5kw |
1670 | 2200×2160×2864 | |
| XB2500 | Φ2500×2500 | 11.2 | 650 | 280 | Y200L1-6 18.5kw |
3450 | 2720×2720×3460 | |
| XB3000 | Φ3000×3000 | 19.1 | 700 | 210 | Y225S-8 18.5kw |
4700 | 3280×3220×3970 | |
| XB3500 | Φ3500×3500 | 30 | 850 | 230 | Y225M-8 22kw |
7300 | 3720×3720×4500 | |
| Lift agitation vat | TXB1000 | Φ1000×1000 | 1 | 350 | 497 | Y112M-4 4kw |
870 | 1300×1130×1300 |
| TXB1200 | Φ1200×1200 | 1.4 | 400 | 497 | Y132S-4 5.5 |
1200 | 1470×1330×1810 | |
| TXB1500 | Φ1500×1500 | 3 | 450 | 402 | Y132M-4 7.5kw |
1460 | 1800×1660×2110 | |
| TXB2000 | Φ2000×2000 | 7.5 | 550 | 353 | Y200L1-6 18.5kw |
3400 | 2160×2160×3000 | |
| TXB2500 | Φ2500×2500 | 12.3 | 650 | 305 | Y200L2-6 22kw |
4500 | 2660×2660×3500 | |
