I.Product Performance and Features
1. EP ≤ 0.08.
2. Separation efficiency ≥ 90%.
3. Adjustable insertion depth for overflow pipe.
4. The Hydrocyclone is lined with wear-resistant high-alumina ceramics and silicon carbide material.
5. Compared with the coal spiral separator or the teeter bed separator, the effective separation size limit of the slime heavy medium cyclone can reach 0.1mm, and the Ep value is lower.
II.Main Technical Parameters
|
Model |
Cylinder diamemter（mm） |
Pressure（MPa） |
Maximum granularity（mm） |
Processing capacity（t/h） |
Pulp capacity（m³/h） |
|
SmaxMZ150 |
150 |
0.12–0.18 |
0.5 |
4–10 |
20-35 |
|
SmaxMZ 200 |
200 |
0.18–0.22 |
0.5 |
10–15 |
35-55 |
|
SmaxMZ 250 |
250 |
0.22–0.24 |
1.0 |
15–20 |
55-80 |
|
SmaxMZ 300 |
300 |
0.24–0.28 |
1.0 |
20–30 |
80-120 |
|
SmaxMZ 350 |
350 |
0.26–0.30 |
1.0 |
30–40 |
120-160 |
|
SmaxMZ 400 |
400 |
0.28–0.32 |
1.5 |
40–55 |
160-220 |
