I.Technical Features
1. The whole machine design through finite element analysis and calculation, to ensure that the structure is more reasonable and the performance is more reliable.
2. The exciter super "G" vibration strength improves the screening capacity, screening efficiency and media recovery.
3. The linear motion of the sieve body under the action of the exciter realizes the immediate elastic adjustment of the amplitude.
4. Vibration exciter using imported SKF/FAG bearing, low noise, low temperature rise, long service life;
5. The side panel and beam are protected by imported anti-corrosion and wear-resistant materials.
6. The side plate is made of special structural steel plate, laser cutting, the installation hole cutting molding, dimensional accuracy and position accuracy is high; Before the whole machine leaves the factory, special instruments are used for static and dynamic performance tests to ensure that the products are qualified.
II.Technical Specifications
|
Model |
Number of Layers |
Width × Length (m) |
Screen Mesh Size (mm) |
Screen Surface Area (m²) |
Feed Particle Size (mm) |
Processing Capacity（t/h） |
Power（kw） |
|
SX-2-1861B |
2 |
1.8×6.1 |
0.5-50 |
2×10.98 |
≤300 |
≤300 |
37 |
|
SX-1-1861B |
1 |
1.8×6.1 |
0.5-13 |
10.98 |
≤100 |
≤100 |
22 |
|
SX-2-1861A |
2 |
1.8×6.1 |
6-100 |
2×10.98 |
≤300 |
≤300 |
37 |
|
SX-1-1861A |
1 |
1.8×6.1 |
6-100 |
10.98 |
≤300 |
≤300 |
22 |
|
SX-2-2461B |
2 |
2.4×6.1 |
0.5-50 |
2×14.64 |
≤300 |
≤300 |
45 |
|
SX-1-2461B |
1 |
2.4×6.1 |
0.5-13 |
14.64 |
≤100 |
≤100 |
30 |
|
SX-2-2461A |
2 |
2.4×6.1 |
6-100 |
2×14.64 |
≤300 |
≤300 |
45 |
|
SX-1-2461A |
1 |
2.4×6.1 |
6-100 |
14.64 |
≤300 |
≤300 |
30 |
|
SX-2-3061B |
2 |
3.0×6.1 |
0.5-50 |
2×18.3 |
≤300 |
≤300 |
55 |
|
SX-1-3061B |
1 |
3.0×6.1 |
0.5-13 |
18.3 |
≤100 |
≤100 |
45 |
|
SX-1-3061A |
1 |
3.0×7.3 |
0.5-13 |
21.9 |
≤100 |
≤100 |
45 |
|
SX-1-3073B |
1 |
3.0×6.1 |
6-100 |
18.3 |
≤300 |
<300 |
45 |
|
SX-1-3073A |
1 |
3.0×7.3 |
6-100 |
21.9 |
≤300 |
≤300 |
45 |
|
SX-2-3661B |
2 |
3.6×6.1 |
0.5-50 |
2×21.96 |
≤300 |
≤300 |
75 |
|
SX-1-3661B |
1 |
3.6×6.1 |
0.5-13 |
21.96 |
≤100 |
≤100 |
55 |
|
SX-1-3373B |
1 |
3.6×7.3 |
0.5-13 |
26.28 |
≤100 |
≤100 |
55 |
|
SX-1-3661A |
1 |
3.6×6.1 |
6-100 |
21.96 |
≤300 |
≤300 |
55 |
|
SX-1-3673A |
1 |
3.6×7.3 |
6-100 |
26.28 |
≤300 |
≤300 |
55 |
|
SX-1-4261B |
1 |
4.2×6.1 |
0.5-13 |
25.62 |
≤100 |
≤100 |
75 |
|
SX-1-4392B |
1 |
4.3×9.2 |
0.5-50 |
39.56 |
≤100 |
≤100 |
2×55 |
|
SX-1-4261A |
1 |
4.2×6.1 |
6-100 |
25.62 |
≤300 |
≤300 |
75 |
|
SX-1-4392A |
1 |
4.3×9.2 |
6-100 |
39.56 |
≤300 |
≤300 |
2×55 |
