Compact Portable PLUS Series
Model:
KY-150 PLUS
Propulsive Force:
Empty Propulsion Speed:
Drilling Diameter:
47, 60, 75mm
COLLECT
Chifeng Dingzun Drilling Equipment Co., Ltd.
Neimenggu · Chifeng
Main Products:Full hydraulic exploration drilling rig KY-150, KY-200, KY-300, KY-500, KY.600, KY-800, KY-1000, KY-1200, KY-1500, PLUS and a series of geological exploration drilling rigs, drilling tools and rig accessories
Enter the store
Details Parameters
Details Introduction

MAIN FEATURES

1. Portable
2. Compact structure, small size, suitable for confined spaces
3. Easier disassembly, handling, and transportation
4.The drill head can be equipped with a side shift, making wireline coring more convenient.

TECHNICAL PARAMETERS OF SMALL PORTABLE PLUS SERIES

Technical parameters of KY-150 PLUS model
Drilling angle 0-360°
Drilling diameter mm   47  60  75
Drilling depth m Down 180 150 100
m Level 150  100  80
m UP 90  60  40
Rotation speed r/min 400-1000
Spindle output torque N.m 280-100
Rated feed force KN 19
Rated Lift Force KN 12
Rated Pulling Speed m/s 0.7
Rated power KW 22
Total weight Kg 1100



Technical parameters of KY-200 PLUS model
Drilling angle 0-360°
Drilling diameter mm   47  60  75
Drilling depth m Down 200  180  150
m Level 200  150  120
m UP 80  70  60
Rotation speed r/min 350-1000
Spindle output torque N.m 350-80
Rated feed force KN 22
Rated Lift Force KN 15
Rated Pulling Speed m/s 0.7
Rated power KW 30
Total weight Kg 1200





Technical parameters of KY-300 PLUS model
Drilling angle 0-360°
Drilling diameter mm   47  60  75
Drilling depth m Down 300  260  220
m Level 250  250  200
m UP 100  100  90
Rotation speed r/min 350-1000
Spindle output torque N.m 700-190
Rated feed force KN 22
Rated Lift Force KN 37
Rated Pulling Speed m/s 0.7
Rated power KW 37
Total weight Kg 1300
