Specifications and Model
|
Specification and Model |
Material Quality |
|
150*750 |
high manganese steel |
|
250*400 |
high manganese steel |
|
250*750 |
high manganese steel |
|
250*1000 |
high manganese steel |
|
250*1200 |
high manganese steel |
|
300*1300 |
high manganese steel |
|
400*600 |
high manganese steel |
|
600*900 |
high manganese steel |
|
900*1200 |
high manganese steel |
|
750*1060 |
high manganese steel |
|
Grade |
"Main chemical composition (mass fraction) / % |
||||||||
|
ZG120Mn13Cr2 |
C |
Si |
Mn |
P |
S |
Cr |
Mo |
Ni |
W |
|
1.05-1.35 |
0.3-0.9 |
11-14 |
≤0.060 |
≤0.040 |
1.5-2.5 |
-- |
-- |
-- |
|
|
Yield strength |
Tensile strength |
Elongation after fracture |
Impact absorption energy |
||||||
|
≥390 |
≥735 |
≥20 |
≥96 |
||||||
At room temperature, the Brinell hardness of the casting is ≦300HBW, meeting the requirements of GB/T5680-2023 standard.
At room temperature, the tensile properties and impact properties of the casting meet the requirements of GB/T5680-2023 standard.
Surface Quality:
- The castings are free of cracks, cold shuts, undercuts, slag inclusions, blowholes, shrinkage holes, porosity, and other casting defects that affect performance.
- The castings have undergone mechanical grinding, resulting in a clean surface with no burrs, fins, or sand adherence.
Product Advantages:
- Adopting the lost foam casting process, the surface is smooth and the interior is dense.
- High-quality modifiers are added during pouring, combined with high-frequency vibration to refine grain structure, achieve a dense microstructure, and enhance the strength and wear resistance of the castings.
- The liner plates wear evenly, ensuring stable and reliable quality, eliminating the need for mid-life replacements.
- The lost foam casting process is environmentally friendly, promoting energy conservation and emission reduction.
